Foton Auman 14m³/16m³/18m³ compressed garbage truck

Wheelbase: 3950/4500/5150mm

Engine: Yuchai 200/245 horsepower

Total weight: 18000kg

Curb weight: 12500,12000,11400kg

Rated load capacity: 5370,5305,5870,5805,6470,6405kg

Dimensions (length x width x height): 9580,9440,8930,8790,8010,7870×2550×3400mm

Effective volume: 14/16/18 cubic meters

Packing volume: 2.4 cubic meters

Chassis configuration: Foton Auman planetary body, 3950/4500/5150mm wheelbase, Yuchai 200/245 horsepower, 10.00 steel tires, Fast 8-speed, 10 ton rear axle, 250 double-layer beam, electric doors and windows, central locking, air conditioning, multifunctional steering wheel, cruise control, power take-off, ABS.

Product Name： Foton Auman 14m³/16m³/18m³ compressed garbage truck
Driving Type： 4x2
Garbage container volume(cbm)： 14m³/16m³/18m³
Gross vehicle weight(Kg)： 18000(Kg)

Product Features

Foton Auman 14m³/16m³/18m³ compressed garbage truck

Compressed garbage truck: composed of a sealed garbage bin, hydraulic system, and operating system, it compresses and pours itself. During the compression process, all the sewage enters the sewage tank, which completely solves the problem of secondary pollution in garbage transportation.

Upper configuration:

1. Adopting Q345 manganese steel high-strength plate arc-shaped box, with 5mm edges and 6mm bottom
2. It is composed of a hydraulic mechanism consisting of a box body, a loading mechanism, a compression mechanism, a unloading mechanism, an oil pump, an oil cylinder, a control valve, etc.
3.The loading mechanism consists of a bracket, a connecting rod mechanism, a cam, a hook, etc., and it undergoes bi-directional peristaltic compression.
4.Domestic well-known brand hydraulic systems (Anhui Wanye Pump, Hunan Changsha Domestic Famous Multi way Valve, Compression Special Customized Oil Cylinder);
5.Centralized electronic control system for both the driver's cab and the exterior of the vehicle, using the same CAN bus control system;
6.Vehicle high position clearance lights/edge lights/work lighting, standard pressure doubling valve, 18 cubic meters standard dual pump.

Product parameters

Product Name	Foton Auman 14m³/16m³/18m³ compressed garbage truck
Driving Type	4x2
Garbage container volume(cbm)	14m³/16m³/18m³
Gross vehicle weight(Kg)	18000(Kg)
Curb weight(Kg)	12500,12000,11400(Kg)
Rated weight(kg)	5370,5305,5870,5805,6470,6405(Kg)
Wheelbase(mm)	4500,5150,3950,4700(mm)
Overall Dimension(mm)	9580,9440,8930,8790,8010,7870×2550×3400(mm)
Engine HP	Yuchai 200/245 horsepower
Axle Quantity	2
Transmission Type	8-speed gearbox
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	11R22.5 18PR,10.00R20 18PR,275/80R22.5 18PR, 6+1 spare
Cab	Foton Auman Planet cab
Garbage container material	Q345 manganese steel high-strength plate arc-shaped box, with 5 mm edges and 6mm bottoms,
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
