KAMA compression docking garbage truck

Chassis configuration:
Fuyunlai 1820MM single row lowered height (2150MM) cab, Weichai 130 horsepower engine, Wanliyang 5-speed with auxiliary gearbox, 200MM double deck beam, 1070 rear axle, cut-off brake, dynamic rotation, 7.50R16 all steel tires, original air conditioning, central control, electric window, power take-off, TBOX.
Installation configuration:
Square shaped cargo box, with internal dimensions of 3500 * 1850 * 850+200 (wing cover), central double roof, rear hydraulic tailgate, all-round wing cover, and integrated manual and automatic operation.
The vehicle has a height of 2180 and is easy to operate both indoors and outdoors. The curb weight is 4100kg, the actual vehicle weight is not overweight, the external dimensions are consistent, and there is no worry for households nationwide. If the payload is less than 750kg, there are no restrictions on driving in the central urban area. The wingspan cover protects garbage from scattering and avoids secondary pollution. Drive with ease and save labor costs. Weichai engines have a significant fuel saving effect, with no more than 6 cents of fuel per kilometer when unloaded. The vehicle has rich configurations and complete functions, and traditional dump truck functions in various regions have been basically fully equipped, making it versatile.

Product Name： KAMA compression docking garbage truck
Driving Type： 4×2
Weight /Volume：
Garbage container dimension(mm)： 3290,3590×1800×1000

Product Features

The types of garbage trucks include: compression garbage truck, self dumping garbage truck, swing arm garbage truck, pull arm garbage truck, hook arm garbage truck (box detachable garbage truck), sealed garbage truck, hanging bucket garbage truck (self loading and unloading garbage truck)

Docking garbage truck, also known as garbage compression station docking garbage truck, is a specialized vehicle used for garbage transfer and unloading operations in urban garbage compression stations.

Product parameters

Product Name	KAMA compression docking garbage truck
Driving Type	4×2
Weight /Volume
Garbage container dimension(mm)	3290,3590×1800×1000
Rated payload weight(kg)	465
Dimensions
Wheelbase(mm)	3300
Overall Dimension(mm)	5650×2100×2180(mm)
Engine
Engine brand & model	Weichai,WP2.3NQ130E61
Displacement(L)/Power(kw)	2.3L/96KW
Chassis
Axle Quantity	2
Transmission Type	5 forward gears and 1 rear gear
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	7.00R16LT 8PR, 6 with a spare
Cab
Standard configuration	KAMA cab
Air conditioning	YES
Performance parameter
Garbage container material	High quality carbon steel plate fully sealed welded structure
Standard configuration	Made of high-quality carbon plates of national standard thickness from Wugang, with a 3mm thick edge and 4mm thick bottom skeleton carriage. The skeleton carriage is designed and manufactured according to the optimized outer frame style that can withstand the maximum pressure.
Other	The matching garbage bin can be customized.
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
