Dongfeng Tianjin 4X2 Swill Truck

Chassis configuration:

Dongfeng Tianjin original chassis, B6.2NS6B230 engine, Shaanxi Gear 8JS95E-C box, 2315 cab, 4.5T front axle, 10T rear axle, 10.00 steel wire tires, 250mm beam, air brake, air conditioning, electric doors and windows, central locking.

Product Name： Dongfeng Tianjin 4X2 Swill Truck
Driving Type： 4×2
Gross vehicle weight(Kg)： 18000kg
Curb weight(Kg)： 9000,8700,8500kg

Product Features

Dongfeng Tianjin 12m³/13m³/14m³ kitchen waste truck

A kitchen waste truck is a specialized vehicle used for collecting and transporting kitchen waste. Also known as meal waste truck, kitchen waste truck, or swill truck, it is usually used to collect kitchen waste generated by hotels, schools, units, large enterprises, agricultural markets, and other places, including swill, leftovers, leftovers, bones, vegetable roots, leaves, fruit peels, and other food waste.

Installation configuration :

Upper configuration:Made of Q710 high-strength steel, with a 4mm edge and 5mm bottom, reinforced square tank body, using well-known domestic hydraulic systems (domestic well-known oil pump, Hunan Changsha domestic well-known multi way valve, customized oil cylinder for kitchen use, Zhejiang Jiashan power take-off),
1. Equipped with a push plate filter to achieve the function of dry wet separation, and a push plate for unloading;
2. Equipped with a high-pressure pump and a high-pressure reel, it achieves the function of high-pressure cleaning;
3. Equipped with PLC electronic control system and wireless remote control, making operation more convenient;
4. The back cover is hydraulically opened and locked, with a sealing strip and an adjustable hydraulic locking pin to ensure no water leakage. 5. Optional pull rod or chain hoist, capable of hanging 120L/240L standard plastic trash cans.
Note:The kitchen waste truck can be equipped with functions such as dry wet separation, high-pressure cleaning, electronic control, heating, etc. according to usage needs. Please confirm the configuration requirements before placing an order.
Top optional simple configuration:
1. The back cover is hydraulically opened and locked, with a sealing strip and an adjustable hydraulic locking pin to ensure no water leakage.

2. Optional pull rod or chain hoist, capable of hanging 120L/240L standard plastic trash cans.
3. Mid mounted double top lifting unloading, the unloading angle can be adjusted according to demand.
4. Having a wireless remote control is more convenient for operation.

Product parameters

Product Name	Dongfeng Tianjin 4X2 Swill Truck
Driving Type	4×2
Gross vehicle weight(Kg)	18000kg
Curb weight(Kg)	9000,8700,8500kg
Rated weight(kg)	8805,8870,9105,9170,9305,9370kg
Wheelbase(mm)	3950/4500/4700mm
Overall Dimension(mm)	7800×2500,2550×3100,3300,3400,3500,3600mm
Engine	Cummins 230 horsepower/DDI 210 horsepower
Axle Quantity	2
Transmission Type	8-speed transmission
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	10.00 steel wire tire, 6+1 spare
Cab	Dongfeng Tianjin cab
Volume(m³)	12m³/13m³/14m³
Tank body	Using Q710 high-strength steel, with 3mm edge plates and 4mm bottom plates
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
