Dongfeng F7 4X2 Kitchen Waste Truck

Chassis configuration:D30TCIF, Yunnei 170 horsepower engine, Fast 8-speed gearbox, 2020 single row cab, 3800mm wheelbase, 3.5T front axle, 7-ton rear axle, 188x6 double-layer beam, 8.25R20 steel wire tires, air brake, ABS， Air conditioning, electric doors and windows, central locking system.

Upper configuration:Made of Q710 high-strength steel, with 4 sides and 5 bottoms, reinforced square tank body, using well-known domestic hydraulic systems (domestic well-known oil pump, Hunan Changsha domestic well-known multi way valve, customized oil cylinder for kitchen use, Zhejiang Jiashan power take-off), hydraulic opening and locking of the back cover, with sealing strip and adjustable hydraulic locking pin to ensure no water leakage. The double chain elevator can hang 120L/240L standard plastic trash cans, ensuring smooth loading.

Product Name： Dongfeng F7 4X2 Kitchen Waste Truck
Driving Type： 4×2
Gross vehicle weight(Kg)： 11995(Kg)
Curb weight(Kg)： 6150(Kg)

Product Features

Dongfeng F7 4X2 Kitchen Waste Truck

Kitchen waste truck, also known as meal waste truck, kitchen waste truck or swill truck, is a type of garbage truck used for collecting and transporting household waste, food waste (swill) and urban sludge.

Product parameters

Product Name	Dongfeng F7 4X2 Kitchen Waste Truck
Driving Type	4×2
Gross vehicle weight(Kg)	11995(Kg)
Curb weight(Kg)	6150(Kg)
Rated weight(kg)	5650,5715(Kg)
Wheelbase(mm)	3800(mm)
Overall Dimension(mm)	6860,6360×2360×2950(mm)
Engine	D30TCIF1, Yunnei 170hp
Axle Quantity	2
Transmission Type	Fast 8-speed gearbox
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	8.25R20 steel wire tire, 6+1 spare
Cab	Dongfeng F7 cab
Volume(m³)	9m³
Tank body	Q345 manganese steel high-strength plate circular tank body is used, with a thickness of 6mm,
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
