Sinotruk HOWO 6X4 16-ton foam fire truck

Product description

Sinotruk HOWO 6X4 16-ton foam fire truck: The whole vehicle is composed of the fireman's crew room and the car body. The crew room is an original double row, which can accommodate 2+4 people. The roof is equipped with red long row alarm lights, three red combination flash lights on both sides, and one light on the rear. The car is an exposed tank structure. The front of the car body is a equipment box, the middle is a tank, and the rear is a pump room. The liquid tank is made of high-quality steel plate. The foam tank is made of 304 stainless steel, with a water capacity of 9000 kg, and foam liquid of 3000 k9. It is equipped with a domestic first-line brand Shanghai Rongshen CB10/60 fire pump, with a rated flow of 60 L/s. The top of the car is equipped with Chengdu Wester PL8/48 fire monitor, foam Range>60m, water range>65m, clear control panel, good control, complete equipment, reasonable setting, easy access, aluminum alloy roller shutter door, aluminum alloy ladder

Product Name： Sinotruk HOWO 6X4 16-ton foam fire truck
Driving Type： 6X4
Total weight（Kg)： 27600(Kg)
Curb weight(kg)： 15150(Kg)

Product Features

Sinotruk HOWO 6X4 16-ton foam fire truck

Foam fire truck is a special vehicle equipped with various fire-fighting equipment or extinguishing agents, mainly used for fire fighting and emergency rescue. It consists of a liquid tank, a pump room, an equipment box, a power output and transmission system, a piping system, and an electrical system. The foam fire truck is suitable for urban public security fire brigade, petrochemical industry, factories and mining enterprises, forests, ports, docks and other departments, especially for petrochemical and other dangerous fire sites.

Product parameters

Product Name	Sinotruk HOWO 6X4 16-ton foam fire truck
Driving Type	6X4
Total weight（Kg)	27600(Kg)
Curb weight(kg)	15150(Kg)
Rated weight(kg)	12000(Kg)
Wheel base(mm)	4600+1350(mm)
Overall dimension(mm)	9700×2500×3565(mm)
Engine brand & model	D10.38-50, 380hp
Axle Quantity	3
Transmission Type	6-speed gearbox, manual
Steering Type	LHD or RHD with power steering
Tire Spec. & size	12.00R20 , 10+1 spare
Cab	Four door flat head all metal enclosed cab, original double row cab, panoramic curved windshield, front bumper, front combination light fixture, electric glass window, front grille lower cover.
Extinguishing Media	water/foam/dry-powder
Tank material	Made of high-quality carbon steel material (Q235), welded structure, equipped with longitudinal and anti sway plates, and treated with epoxy anti-corrosion. 304 stainless steel and PP materials can be selected
Tank volume	12 ton water+4 ton foam
Equipment box	The fire pump is located in the middle or rear of the box, with four water outlets on both sides of the pump room and new high-strength aluminum alloy rolling shutter doors on both sides of the equipment box. The equipment bracket adopts aluminum alloy profiles produced by European technology, with a fully internal hexagonal connection structure manufactured by a concealed tower connection, which is beautiful and durable.
Electrical configuration	The front end of the top of the fire truck cab is equipped with a long row of red warning lights, and a red circular warning light is installed on the top of the rear of the vehicle. There is one 24V and one 60W fire lighting lamp at the front and rear of the roof. The vehicle is equipped with red and blue matching flashing lights on both sides, safety sign lights and side reflectors installed below, front and rear clearance lights, and one turn signal light on each side. Lighting fixtures are installed in the passenger compartment, equipment box, and pump room.
Fire cannon	PL48 fire cannon
Fire pump	CB10/60 fire pump
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
