Dongfeng D6 7.5m³ Side mounted Bucket Garbage Truck

Chassis configuration:

1. Engine: YCY24140-60, Yuchai 140hp

2.Transmission type: 5-speed gearbox

3.Wheelbase: 2700,2950,3308,3600,3800(mm)

4.Tyre: 7.00R16,7.00R16LT, 6+1 spare

5.Other: Dongfeng D6 cab

Product Name： Dongfeng D6 7.5m³ Side mounted Bucket Garbage Truck
Driving Type： 4×2
Gross vehicle weight(Kg)： 7360(Kg)
Curb weight(Kg)： 3810(Kg)

Product Features

Dongfeng D6 7.5m³ Side mounted Bucket Garbage Truck

A side mounted garbage truck is a vehicle specifically designed for collecting and transporting garbage. Its main feature is to load the garbage bin from the side and compress the garbage into the vehicle through a self loading and unloading system. This type of vehicle is usually suitable for garbage collection in narrow areas such as urban alleys and rural roads.

Product parameters

Product Name	Dongfeng D6 7.5m³ Side mounted Bucket Garbage Truck
Driving Type	4×2
Gross vehicle weight(Kg)	7360(Kg)
Curb weight(Kg)	3810(Kg)
Rated weight(kg)	3420(Kg)
Wheelbase(mm)	2700,2950,3308,3600,3800(mm)
Overall Dimension(mm)	5793×2090×2280,2350(mm)
Engine	YCY24140-60, Yuchai 140hp
Axle Quantity	2
Transmission Type	5-speed gearbox
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	7.00R16,7.00R16LT, 6+1 spare
Cab	Dongfeng D6 cab
Volume(m³)	7.5m³
Tank body	Reinforced square tank body, Q710 high-strength steel
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
