Howo TX 6X4 dry powder and foam fire truck

Chassis configuration:

1. Engine: MC11.44-60, 324kW（440hp)

2.Transmission type: 9-speed gearbox

3.Tyre: 315/80R22.5,12.00R20, 10+1 spare

4.Wheelbase:4600+1400(mm)

5.Other:Howo cab, Flat head, four door double row cab, with four air breathing apparatus brackets installed on the rear seats

Product Name： Howo TX 6X4 dry powder and foam fire truck
Driving Type： 6X4
Total weight（Kg)： 28800(Kg)
Curb weight(kg)： 17250(Kg)

Product Features

Howo TX 6X4 dry powder and foam fire truck

The dry powder and foam fire truck is a fire extinguishing equipment that integrates the functions of foam fire truck and dry powder fire truck. It is mainly equipped with vehicle fire pump, water tank, foam liquid tank and dry powder extinguishing agent tank, which can spray dry powder and foam at the same time or in sequence.

Product parameters

Product Name	Howo TX 6X4 dry powder and foam fire truck
Driving Type	6X4
Total weight（Kg)	28800(Kg)
Curb weight(kg)	17250(Kg)
Rated weight(kg)	11100(Kg)
person capacity	2+4 person
Wheel base(mm)	4600+1400(mm)
Overall dimension(mm)	10380×2550×3900(mm)
Engine brand & model	MC11.44-60, 324kW（440hp)
Axle Quantity	3
Transmission Type	9-speed gearbox
Steering Type	LHD or RHD with power steering
Tire Spec. & size	315/80R22.5,12.00R20, 10+1 spare
Cab	Howo cab, Flat head, four door double row cab, with four air breathing apparatus brackets installed on the rear seats
Liquid carrying capacity	6000L water, 2000L foam, 3000L dry powder
Tank material	The water tank is made of high-quality Q235 carbon steel plate, the foam tank is welded with 304 stainless steel, and the dry powder tank body is made of Q345R.
Fire pump	CB20.10/30.60 medium and low pressure fire pump
Fire cannon	PL8/48 dual-purpose fire monitor
Dry powder cannon	PF5-15/30 dry powder monitor
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
